A specially developed high performance yet economical series of low impedance balanced microphone cables. These cables are small in size and special rubber - like PVC jacket is extremely flexible and exhibits good resistance to rough handling and abrasion.
High grade insulation material is designed to minimize heat shrinkage during soldering which allows easy termination to XLR type connectors.
Here is an extremely limp and flexible cable for all types of audio/visual and industrial audio applications. XLPE insulation and a strong rubber - like outer jacket makes this cable ideal where a durable yet economical cable is needed.
Specifications:
| Part No. | W2582 | |
| No. of Conductor | 2 | |
| Conductor | Details | 12/0.12 A |
| Size(mm²) | 0.135mm² (#26 AWG) | |
| Insulation | Ov. Dia.(mm) | 1.5Ø (0.059") |
| Material | LNXLPE (Low Noise Cross-Linked Polyethylene) | |
| Colors | Red / Clear | |
| Served Shield | Approx. 67/0.12A | |
| Jacket | Ov. Dia.(mm) | 6.0ì (0.236") |
| Material | Flexible PVC | |
| Colors | Black / Red / Yellow / Green / Blue / Gray | |
| Roll Sizes | 50m (164 Ft) | |
| 100m (328Ft) | ||
| 200m (656Ft) | ||
| Weight per 200m Roll | 9kg | |
Electronical & Mechanical Characteristics:
| Part No. | W2582 | |
| DC Resistance at 20°C | Inner Cond. | 0.14W/m(0.043W/Ft) |
| Shield | 0.024Ω/m(0.007Ω/Ft) | |
| Capacitance at 1kHz, 20°C | K0 | 90pF/m(27pF/Ft) |
| (Partial C. Value) | ||
| See below figure* | K1 | 10pF/m(3pF/Ft) |
| Inductance between conductors at 1kHz. 20°C | 0.8µH/m(0.24µH/Ft) | |
| Electrostatic Noise** | 50mV Max. | |
| Electromagnetic Noise** | 0.15mV Max. | |
| Microphonics at 50KW Load** | 30mV Max. | |
| Voltage Breakdown | Must withstand at DC 500V/15sec. | |
| Insulation Resistance | 100000 MW × m Min. at DC 125V, 20°C | |
| Flex Life** | 13,800 cycles | |
| Tensile Strength | 441N | |
| Emigration | Non-emigrant to ABS | |
| Applicable Temperature | -20°C‾ +70°C(-4°F‾ +158°F) | |
