Features:
- Switchable boost/cut ranges of 6dB or 12dB
- 12dB per octave 50Hz low-cut filter
- Front-panel bypass switch
- 12dB input gain range
- 4-segment LED ladders for monitoring output levels
- XLR and TRS inputs and outputs
- Internal toroidal transformer
- Dynamic range of greater than 108dB
| Model | H215EQ |
| Type | Dual 15-Band
2/3-Octave Constant Q Frequency Bands |
| Bandwidth | 20Hz to 20kHz, +0.5/-1dB |
| Input Connectors | 1/4" TRS, Female XLR (Pin 2 Hot) |
| Output Connectors | 1/4" TRS, Male XLR (Pin 2 Hot) |
| Power Consumption | 12W |
| Frequency Response | <10Hz to >50kHz, +0.5/-3dB |
| Dynamic Range | 108dB |
| Signal to Noise | 90dB |
| THD + Noise | <0.004% |
| Inter-channel Crosstalk | <-80dB, 20Hz to 20kHz |
| Product Dimensions | 19’’(W) x 6’’(D) x 1.75’’(H) |
| Product Weight | 2.1Kg |
