* 2400 to 3000 selectable frequencies
* Preset 15 groups each of up to 63 compatible channels* Phase-Locked Loop (PLL) synthesized tune
* Adjustable transmission power between Low and High
NEWEST FEATURE :
* Low cut function.
* JTS newest development SAM-8WLN capsule assures outstanding acoustic performance while minimizes touching noise.
* Interchangeable capsule design for various choices including some classic capsule modules.
* It is designed with slot-in charging feature with two AA NiMH rechargeable batteries.
| JSS-20 | |
| Frequency Preparation | PLL Synthesized Control |
| Carrier Frequency Range | UHF 470~960 MHz |
| Bandwidth | 60~75MHz Wideband |
| RF Outputs | Low / High |
| Stability | < ±10KHz |
| Frequency Deviation | ±48KHz (Peak) |
| LCD Display | Group, Channel, Frequency, Battery Status, User Name, GAIN Adjust |
| Controls | Power ON / OFF, AF Level, Frequency (Up / Down), Lock-on Mode, REMOSET ID Pairing, RF Output Adjust |
| Spurious Emissions | <-50 dBC |
| Audio Frequency Response | 50Hz ~ 18k Hz |
| Capsule Module | Interchangeable |
| Battery | AA NiMH x2 |
| Dimensions | 50mm (W) x253mm (H) x35.5mm (D) |
| Weight | 350g |
