* Provides -10dB, -20dB or -30dB attenuation to prevent overload of sensitive input stages.
* Full metal case optimizes shielding from hum.* Designed for balanced low-Z microphone.
* Allowed with phantom power application.
| MA-123 | |
| Frequency Response | 20~20,000 Hz |
| Attenuation | -10dB ±1dB , -20dB ±1dB ,-30dB ±1dB |
| Distortion | -10dB: <0.0011%
-20dB: <0.0012% -30dB: <0.003% |
| INPUT Impedance | 1.6KΩ (-10dB) |
| Output Impedance | 660Ω(-10dB) |
| Frequency Response | 30~20,000 Hz |
| Noise | < -115dB |
| Input Connector | XLR-Female |
| Output Connector | XLR-Male |
| Net Weigh | 50 grams |
| Dimensions(mm) | 20.5mm(W)* 23.5mm(H)*113.4mm(D) |
