SGM-14
| SGM-14 | |
| Type | Electret Condenser |
| Frequency Response | 20~20,000 Hz |
| Sensitivity | -52±3dB*(2.5mV)*0dB=1V/μbar |
| Polar Pattern | Hypercardioid |
| Attenuation Switch | -10 dB |
| Low Frequency Roll-off | 80 Hz |
| Impedance | Rated impedance is 200Ω |
| Max. SPL for 1% THD | 125dB (135dB with -10 dB Attenuation) |
| Signal To Noise Ratio | 78dB |
| Power Supply | 9~48VDC phantom power |
| Output Connector | 3P XLR (M) |
| Length | 355.7mm |
