Features
- Built-in digital controller allows transposing the key of music over 5 tones. in ±4 position. (Reset automatically at the end)
- Built-in high quality digital echo
- 1-4 parallel connection capability of 8Ω speakers
- Five line inputs manually controlled
- Five microphone available simutaneously
- Voice cut/change feature for cutting off the vocal part of a multiplex audio disc is provided as standard
- Remote control included
Included Accessories
- Remote Control Unit
- Owner's Manual
- Fuse T8AL 250V
- Audio Cord
| Maximum Output (1KHz, 4Ω, THD2%) | 220W+220W/4Ω |
| Total Harmonic Distortion | 0.1% (1KHz, 200W, 4Ω) |
| Input Jacks (Sensitivity/Impedance) | |
| Mic (1, 2, 3, 4, 5) | 14mV/5kΩ |
| VOD, DVD, TAPE | 230mV/23kΩ |
| Output Jacks (Output Level/Output Impedance) | |
| PRE OUT | 1500mV/150Ω |
| TAPE OUT | 200mV/470Ω |
| Frequency Respond | |
| MIC | 40Hz to 12KHz, -1/+2dB |
| MUSIC | 20Hz to 20KHz |
| Tone Control Characteristics | |
| Music BASS | ±10dB (100KHz) |
| MID | ±10dB (1KHz) |
| TREBLE | ±10dB (10KHz) |
| Microphone Bass | ±7dB (100KHz) |
| MID | ±7dB (1KHz) |
| TREBLE | ±7dB (10KHz) |
| Supply Voltage | AC240V 50Hz |
| Power Consumption | 300W |
| Dimensions (W x H x D) | 430mm x 148mm x 370mm |
| Mass | 11.6kg |
