INTEGRAL-VC1 is a 100V volume control capable of handling power up to 120W. The volume is adjustable with a rotatable selector in 5 steps of -6dB. It is equipped with a relay and separated input for the reception of 24V priority signals. When a priority signal is sent to the controller the volume will automatically switched to the maximum level. This is a very useful tool for emergency and evacuation purposes.
| Electronics | |||||
| Power Handling | 120 W | ||||
| Frequency Response | 20 Hz – 20 kHz | ||||
| Taps | Tap 1 | Tap 2 | Tap 3 | Tap 4 | Tap 5 |
| 0 dB | -6 dB | -12 dB | -18 dB | OFF | |
| Attenuation | 6dB | ||||
| Dimensions-Weight | |||||
| Dimensions ( H x W x D ) | 86 x 86 x 52 mm | ||||
| 3,4 x 3,4 x 2,0 in | |||||
| Net Weight | 0,5 kg ( 0,2 lb ) | ||||
