- BC-T Series encloses the transmitter PCB for wireless transmission and can also connect directly with MM-206 / MM-205 / MM-204 gooseneck microphone.
- For wired transmission, the output jack requires phantom power from the mixer.
- For wireless transmission, the operational controls are the same as the ACT-T Series bodypack transmitters. A built-in ICR 18500 rechargeable lithium battery can be charged by an external charger or simply replace with another spare battery.
- A TALK / MUTE button with a LED indicates TALK (LED on) or MUTE (LED off).
| Model | BC-100T |
| Name | UHF Wireless Conference Microphone Base |
| Built-in Transmitter | ACT-32TC (UHF analog) |
| Receiver | ACT-300/500 series |
| Input Jack | 4 pin XLR female |
| Output Jack | Balanced XLR male |
| Microphones | MM-204 / MM-205 / MM-206 gooseneck microphone |
| TALK / MUTE Button | Mechanical PUSH-HOLD switch, with a LED status indicator |
| Power Supply | One ICR 18500 lithium-ion battery and the charging circuit |
| Phantom Power | 24 ~ 48 V DC phantom power is required (external cable) |
| Color | Black |
| Dimensions | 100 × 78 × 150 mm (W×H×D) |
| Net Weight | Approx. 710 g |
| Note | Refer to actual product in the event of product discrepancy. |
