DSPPA 250 Watts 2 Zone Integrated Mixer Amplifier with Bluetooth/USB/FM Tuner & Remote Paging

MP-600U

DSPPA

Whatsapp for enquiry Email for enquiry






MP600U  Stereo Mixer Amplifier is a 2-zone mixer amplifier integrated with the functions of USB flash disk, FM, Bluetooth, zone and remote paging. It features various functions, including clear screen display of status, EMC IN, MIC IN with phantom power, priority of inputs, user-friendly and easy to use. The device can meet the requirements of the users and can be widely used.


Features

● Rated power 250W
● With a band code LCD screen and intuitive display, easy to use.
● 4 audio source modes: AUX/BLUETOOTH/FM/USB.
● With a remote control interface, can be used with an RM20 paging station
● 2 AUX IN, independent AUX input volume control
● With short-circuit no output and temperature protection
● Priority: MUTE>EMC=MIC1>RM20=CHIME=SIREN>MIC2/3/4>AUX


Model

MP600U

MP1000U

Rated Input Voltage

AC220-230V/50Hz-60Hz/4A

Rated Output Power

250W

350W

Input Sensitivity

MIC1 IN: 15±3mV (Unbalanced 6.35 IN)

MIC2-MIC4 IN: 10±2mV (Balanced XLR IN)

AUX IN: 350mV±50mV(Balanced RCA IN)

EMC IN: 600mV±50mV(Unbalanced European terminal)

Frequency Response

60Hz-16KHz

THD

≤1%

Display Screen

LCD screen with multi-function band code

SNR

≥75dB

Master Volume

With digital master volume adjustment from 0-32 levels

Tone Range

Bass: 100Hz±10dB

Treble: 10KHz±10dB

RS485 Interface

RS485 communication protocol

Phantom Power

+24V

Interfaces

AUX IN

2 channels

EMC IN

1 channel

LINE OUT: 1V

1 channel

Functions

CHIME

Support

SIREN

Support

MUTE

Support

Bluetooth

Support

FM

Support

MP3

Support

Zone

2 zones

Remote Controller

Optional

DC24V IN

Support

Remote Paging

Support up to 2 RM20 paging stations

Power Consumption

Rated Power(DC24V)

400W

550W

Static Power (DC24V)

25W

25W

Rated Power (AC230V)

450W

550W

Static Power (AC230V)

35W

35W

Dimension and Weight

Package Dimension (HWD)

170mm*541mm*541mm

Product Dimension (HWD)

88mm*420mm*403mm

Gross Weight

12.5kg

13.5kg

Net Weight

11.7kg

12.7kg
