TOA Speaker Selector SS-1010 is a 10 Input Zone and 1 input Emergency Override speaker selector. This highly efficient speaker selector can be installed with public address system in schools, malls, offices and places that requires the selection of speakers.
| Voltage Source | 24V DC | |
|---|---|---|
| Current Consumption | 0.4 A DC | |
| Inputs | 10 Inputs Zone | |
| 1 Emergency Override | ||
| Outputs | 10 Outputs Zone, each output max. 480W | |
| Control Switch | Front | 10 Zone Selectors |
| 1 All Zone Selector for All Zone | ||
| Rear | 1-10 Zone Controls In | |
| All Zone Control In for All Zone | ||
| Indicator LED | 10 Zone Selector LEDs | |
| 1 All Zone LED | ||
| Operating Temperature | 0 °C to 40 °C | |
| Finish | Front Panel: Aluminum Hair Line, Etching Black
Case: Steel Plate, Painting Black |
|
| Dimensions | 420 (W) × 44 (H) × 320 (D) mm | |
| Weight | 3.2 kg | |
| Accessory | 6P Connectors x 12 pcs, 2P Connectors x 1 pcs
|
|
