TOA Quad-Channel 640 Watts Pro Series Power Amplifier (8 Ohms)

DA-1000F

TOA

Whatsapp for enquiry Email for enquiry






The DA-1000F multichannel power amplifier is excellent solution to sound application that requires high power density. Featuring 4000W, quadruple channels, you can now handle the high power TOA HX-7 at ease.


Power Source 100 - 240 V AC, 50/60 Hz
Amplification System Class D
Power Consumption 2000 W *1
Input CH 1-4: 20kΩ (balanced) / 10kΩ (unbalanced), 0.775/1.0V/32dB*2, XLR-F connector
Output LINK CH 1-4: XLR-M connector
Speaker 1-4:
                   4 channels: 650 W × 4 (8 Ω)*3, 1000 W x 4 (4 Ω)*3
                   2 channels (BRIDGE): 2000 W × 2 (8 Ω)*3
                   NL4 SPEAKON connector
Frequency Response 20 Hz - 20 kHz (±3 dB)
Total Harmonic Distortion ≤ 0.1 %
S/N Ratio ≥ 100 dB
LED Indicator Protect (Red) / Clip (Red) / -5dB (Green) / -10dB (Green) / -20dB (Green) / Signal (Green) / Power (Green)
Cooling Air flow from front to rear
Operating Temperature 0 ℃ to +35 ℃ (32 ゜F to 95 ゜F)
Operating Humidity 80 %RH or less (no condensation)
Finish Case: Plated steel sheet, black
Dimensions 483 (W) × 89 (H) × 461 (D) mm
Weight 9.2 kg
Accessory Power cable …1
